15ft. 7-Way Electrical Plug Trailer RV Towing Camper Color Coded Wiring Harness

Description

Features:

• 15ft. 7-Way Electrical Plug Trailer RV Towing Camper Wiring Harness
• Heavy Duty Cable is Weather, Chemical, Moisture and Abrasion Resistant
• Color-Coded Wires Allow for Simple, Secure Installation of RV and Towing Hook Up
• Designed for RV Trailers, Campers, Caravans, Food Trucks and Other Towed Vehicles
• 7-Way Connects Brake, Running, Reverse, Turn Signals, and Auxiliary Power

Specifications:

• Length: 15 ft.
• Connector:
  • 7 Way Copper Spade Connector
  • 7 Color Coated Wires (for you to hook up to the proper wires on your trailer)
• Wire Gauge:
  • Yellow, Green, Brown, Red: 14 Gauge
  • Blue: 12 Gauge
  • White and Black: 10 Gauge
• Brand: Biltek
• Condition: 100% Brand New

Wiring Diagram:

• White = Ground
• Blue = Brake
• Brown = Right Turn / Stop
• Black = Auxiliary
• Green = Running / Marker
• Red = Left Turn / Stop
• Yellow = Reverse Light

Package Includes:

• 1x 15ft. 7-Way Electrical Plug
• Instructions not included

WARNING: Misuse can result in FIRE or DEATH by ELECTRICAL SHOCK. Keep away from children and pets. Keep away from water. Fully uncoil before use. Read and follow all safety instructions before use.
