Blue Line Stator Type 2 (11 Coil, 5 Wire); GY6

Description

Blue Line’s 11 coil stator is the ideal upgrade for a GY6 swapped Honda Ruckus.  Upgrade your 6 or 8 pole wired GY6 engine with this vastly superior and high quality replacement. Does not include flywheel; this version does (SKU 0900-1098).

Original Parts For Scooters SKU 164-290

Specifications:

• AC
• Diameter: 88mm
• Width: 30mm
• Bolt Hole Spacing: 41mm
• Bolt Hole Diameter: 6mm
• Coil Wire Length: 23 inches
• Number of Coils: 11
• Plug Style: 4-pin, female with two separate single pins
• Plug Colors 3 Yellow, 1 Green, 1 Blue, 1 Red/Black

Compatibility:

157QMJ-based 125cc / 150cc / 169cc engines with the following engine codes:

Don’t see your engine listed? If the engine code includes “QM” or “FM”, this product is compatible with your vehicle.

About Blue Line: Blue Line offers OEM equivalent replacement parts for on-road scooters. Blue Line parts are a direct-fit replacement when OEM parts are unavailable or overly expensive for your scooter. Since 2018, Blue Line has provided quality parts at great prices.
