Fuel Pressure Regulator ALL40290

Sale!
Fuel Pressure Regulator ALL40290

Fuel Pressure Regulator ALL40290

Original price was: $47.99.Current price is: $37.02.

93 in stock

SKU: ALL40290 Category:

Description

Allstar Fuel Pressure Regulator ALL40290

Place regulator between fuel pump and carburetor to regulate fuel pressure when using mechanical and electric performance fuel pumps. Two piece aluminum body has a single 3/8″NPT inlet port on the bottom and two 3/8″NPT side outlet ports. “Dead Head” style regulator does not require a return line back to fuel tank or cell. 1/8″ NPT port for mounting a fuel pressure gauge or sender line. Regulator also includes steel mounting bracket.

Product Info
Alternate Description FUEL PRESSURE REGULATOR
Part Number ALL40290
Vendor Part Number ALL40290
UPC Code 848238020953
Package Weight
0.62 lbs 0.28 kg
Package Length
7 in 17.78 cm
Package Width
4 in 10.16 cm
Package Height
1.95 in 4.95 cm
Attributes
Bypass No
Adjustable Yes
Adjustment Range Low 4-1/2 PSI
Adjustment Range High 14 PSI
Mounting Style In-Line
Inlet Size 3/8 in NPT
Inlet Style Female
Outlet Quantity 2
Outlet Size 3/8 in NPT
Outlet Style Female
Gauge Port Yes
Gauge Port Size 1/8 in NPT
Gauge Port Style Female
Bracket Included Yes
Gasoline Compatible Yes
E85 Compatible Yes
Material Aluminum
Color Black
Finish Anodized
Quantity Each
