NCY Oil Cooler; GY6, Genuine

Description

The NCY oil cooler 17mm kit is an excellent addition to your high-performance or stock Geniune 125-170cc scooter or 125/150cc  GY6-powered vehicle. Increase engine power, reduce engine temperature, and prevent the thermal breakdown of engine oil.

Specifications:

• Alumin-Alloy Drain Banjo Adaptor ID: M30x1.5mm / Port ID: 10mm / OD: 39mm / H: 36.5mm
• Metal Adaptor Spanner Wrench L: 150mm / W: 18.2<33.6mm / H: 14.2mm
• 2 Alumin-Alloy Banjo Fittings ID: 6<10mm / L: 40.5mm / W: 17.2mm / H: 15.5mm
• 2 Stainless Steel Banjo Bolts ID: M10x6mm / OD: 12<15mm / L: 28.7mm
• 4 Banjo Bolt Copper Washers ID: 10.3mm / OD: 13.8mm / H: 1mm
• Alumin-Alloy Spring Post ID: 14mm / OD: 16<26.4mm / H: 17mm
• Spring Post Rubber O-ring ID: 20mm / OD: 24.5mm / H: 3mmMetal Spring ID: 16.9mm / OD: 28.9mm / L: 35.4mm
• Alumin-Alloy Filter Canister ID: M30x1.5mm / OD: 17<42.8mm / L: 89.6mm
• Alumin-Alloy Filter Canister Donut ID: 15mm / OD: 27.6mm / H: 7mm
• 2 Cap Rubber O-rings ID: 30mm / OD: 33mm / H: 3mm
• Alumin Radiator L: 160mm / W: 32<35.3mm / H: 102mm
• 2 Alumin-Alloy Radiator Fittings ID: M12x6mm / OD: 17<18.7mm / L: 36.4mm
• 2 Radiator Fitting Copper Washers ID: 12.2mm / OD: 17.8mm / H: 1.2mm
• Silicone Oil Hose ID: 6.4mm / OD: 12mm / Rate: 300psi / L: 4.25-ft (1,295mm)

Compatibility:

157QMJ-based 125cc / 150cc / 169cc engines with the following engine codes:

Don’t see your engine listed? If the engine code includes “QM” or “FM”, this product is compatible with your vehicle.

About NCY: NCY is the aftermarket performance parts leader for most popular scooter brands including Honda, Yamaha, Genuine, Vespa, SYM, Lance, KYMCO, and GY6 / QMB powered scooters. Made in Taiwan with strict quality standards since 1997, NCY is ISO 9001 certified.

Made in Taiwan.

This product is intended for off-road use only.

This product is not intended for use on public roads or land.

This product is not legal for use in California on pollution-controlled vehicles. Check local laws before installing.

*Performance upgrades are considered racing parts and are not covered by warranty.
