S&S Cycle Camshaft Kit – 33-5268 For Harley Motorcycles 2006-2017

Description

Designed for 88/96/103/110 cubic-inch engines with compression ratios from 10.0:1 to 10.5:1Reverses the rear cam’s direction of rotation, providing additional operating clearance between cam lobes making higher cam lifts possibleIncreases valve timing accuracy by eliminating chain lash and loosely fit stock chain driveMaterial must be removed from inner surface of the stock gear cover to install3500-6000 rpm for 88″ to 103″ engines and 2500-5500 rpm for larger enginesA hydraulic press and other professional level tool are required for installationS&S recommends that adjustable pushrod/cover get be usedCam bearings and gaskets must be replaced when installing new camsKit includes camshafts, inner gears, outer gears, inner bearings, outer bearings, gasket and instructionsInstaller must check coil bind, valve to valve clearance and valve to piston clearance.Due to the inherent characteristics of gear drives, more valve train noise may occur.Made in the USASpecsProduct NameCamshaft KitTypeGearApplicationExhaust / IntakeGrind585 SeriesIntake Lift at TDC0.186″Intake Open20°Intake Lift0.585″Intake Duration245°Intake Lobe Centerline102.5°Intake Close45°Exhaust Lift0.585″Exhaust Duration260°Exhaust Lobe Centerline110°Exhaust Lift at TDC0.179″Exhaust Open60°Exhaust Close20°UnitsKitRiding StyleStreet
